Fusion MS-AM402 Amplifier 2 Channel 400 Watts

$75.50 $150.99

Fusion MS-ASM402 2 Channel Marine Amplifier Model: 010-01499-00 UPC: 07537591392471 Class AB Design - The 400 Watt 2-Ohm stable (per channel) design ensures clean and powerful amplification of the input signal, enough to rock the boat. Conformal Coated Cir

Qty:

Payment:

Payment Option Image

Fusion MS-ASM402 2 Channel Marine Amplifier

Model: 010-01499-00
UPC: 07537591392471

  • Class AB Design – The 400 Watt 2-Ohm stable (per channel) design ensures clean and powerful amplification of the input signal, enough to rock the boat.
  • Conformal Coated Circuitry – Provides added protection from salt air and moisture to ensure maximum product life.
  • RCA Line Out – A pass through RCA output enables linking of multiple amplifiers for enhanced system performance
  • 2 Channels – Capable of powering 2 speakers, a sub (bridged) or 4 speakers in parallel.
  • Marien Grade Chassis – Stainless steel end caps and bottom plate provide a stunning finish with added environmental protection.
  • Heat Sink Technology – Transfers heat more efficiently and offers more thermal stability for maximum component reliability.

Specifications

Peak Power 400 Watts
Rated Power 14.4 Volt Power Output Specification
65 Watts RMS x 2 @ 4 Ohm 1% THD+N
100 Watts RMS x 2 @ 2 Ohm 1% THD+N
200 Watts RMS x 1 @ 4 Ohm Bridged 1% THD+N
Signal to noise >95dB
Seperation >60dB
Input sensitivity 300mV – 8V
LP variable crossover 40Hz – 160Hz @ 12dB/octave
HP variable crossover 40Hz – 600Hz @ 12dB/octave
Variable bass boost 0 – + 18dB @ 45Hz
Variable subsonic filter 20Hz – 55Hz @ 18dB/octave
Input impedance 20k?
Damping factor >200
T.H.D. 0.05%
Fuse ratings 1 x 25amp
Dimensions 296mm L x 230mm W x 53mm H (11-2/3? L x 9? W x 2-1/6? H)
